24V DIN Rail Power Supply perfect to run 1 boneIO Controller, either Black or ESP.
Rated 30W load.
You should always calculate load of the devices connected to power supply and leave around 10% of the power free, so it won’t work at 100% of it’s possible load.
For double controller boneIO installation you can choose bigger one Mean Well HDR-60-24
| Dimensions | 35x90x54.5mm |
|---|---|
| Manufacturer | Mean Well |
| Power | 30W |
| Output voltage | 24VDC |
| Output voltage range | 21.6…29VDC |
| Output current | 1.5A |
| Number of outputs | 1 |
| Efficiency | 90% |
| Power consumption without load | <0.3W |
| Supply voltage | 85…264V AC |
| Weight | 142.9g |
| Protection | anti-overload OPP, anti-overvoltage OVP, short circuit protection SCP |
| Warranty | 2 years |
